Radiography Testing for Internal Inspection
What Is It
Seeing Inside With X-Ray & Gamma Radiography
Radiography Testing (RT) uses X-rays or gamma rays to create an image of the internal condition of a component. Different materials and thicknesses absorb radiation differently-this variation creates an image that can reveal internal defects such as cracks, porosity, inclusions and lack of fusion.
IRC provides both X-Ray and Gamma Radiography services, including specialised radiography solutions for shutdown and erection activities.
Our services support applications including:
- Weld Inspection
- Piping Systems
- Pressure Vessels
- Storage Tanks
- Fabricated Components
Why Radiography
Why Choose Radiography Testing?
Internal Visibility
Identify hidden defects that cannot be seen from the surface.
Detailed Imaging
Produce clear radiographic images for evaluation.
Proven Technology
A widely established method for weld and component inspection.
Multiple Sources
X-Ray and Gamma sources can be selected based on inspection requirements.
How It Works
Our Radiography Testing Method
Inspection Preparation
The component and inspection area are prepared according to the required procedure.
Source Positioning
The X-Ray machine or radioactive source is positioned appropriately.
Radiation Exposure
Radiation passes through the component and is captured on the detector or film.
Image Evaluation
The resulting image is examined for indications of internal discontinuities.
Reporting
Results are documented and reported by qualified inspection personnel.
Radiography sources available include X-Ray, Iridium-192 (Ir-192), Cobalt-60 (Co-60) and Selenium-75 (Se-75).
Our Toolkit
Our Radiography Testing Capabilities
X-Ray Radiography
Controlled radiographic inspection using X-Ray equipment.
Gamma Radiography
Portable inspection using suitable radioactive sources.
Se-75 Radiography
Used for specialised applications where appropriate.
Closed Proximity Radiography
Specialised technique for inspections in restricted areas.
Timely inspection support is also available during shutdown and erection activities.
Applications
Applications of Radiography Testing
Weld Inspection
Detection of internal weld defects.
Piping & Pipelines
Inspection of welded joints and critical piping.
Pressure Vessels
Assessment of weld integrity in pressure-containing equipment.
Fabricated Structures
Inspection of critical fabricated components.
Shutdown Projects
Rapid inspection support during maintenance and plant shutdowns.
